Angular Folder Structure Best Practices

Nicely written code and a well arrange folder structure in any project is a haven for the developers. This no different in Angular, the SPA framework Angular comes with its own coding guidelines Style Guide • Angular. The style guide is enough to show you a riotous path for following a coding standard, naming conventions and project structuring. We will touch base the style guide in this article, we will head in this direction for now:

• The Philosophy
• High Level Structure
• Low Level Structure
• Keeping APIs
• Decision Making (Ask Yourself)
• AI Corner

The Philosophy

It's crucial to understand the general philosophy to even have a defined folder structure in the first place. A well-defined folder structure enables developers to locate files as quickly as possible. So, basically, it's a raise against time, the poor the structure the more time it takes to locate files.

Now the arrangement of files can be broadly categorized in two ways,

1. Type Based
2. Feature Based.

In type based, you keep all the same type of files together, for example you clubbed all the components together, and services together. While in the feature based you club things based on their feature or domain, for example you clubbed components or services related to products in one folder and orders in another folder if we talk about any generic E-Commerce based app.

Both the approaches come with their own challenges if your app is big in size. If you consider only type based, then tons of components will be placed inside components folder without clearly distinguish between their features. While in the other approach you need to always logically define your feature boundaries, but with the changing nature of software development approach this becomes challenging later, as the sometime the feature name or context gets changed and then the structure becomes irrelevant over a period of time.

The best folder structure lies an approach that consume goodness of both the philosophy while being lean and clear. At high-level categorize everything based on feature/domain and at the low level organized by type.

High Level Structure

Broadly in Angular, we have certain core things those serve as a basis for any app, certain things those are shared across the apps (some common components like button, grid, etc.) and many features. Lets go with this setup and create three base folders at high level as below:

app
|-- core
|-- features
|-- shared
|-- layout
|-- app.component.ts|html|spec
|-- app.config.ts
|-- app.routes.ts

Here, we have 3 base folders, this categorization is mostly domain based, further we will move into type based or in more specification.

Below highlights the role of these modules and the intent of having them:

1. Core: It contains core/base things of the project. Basically, acting as a main app module; but this is not something that will be bootstrapped to the main file. The core folder will singleton services (provided in root) those are only one for entire project, interceptors, guards etc. The core folder must not be imported elsewhere in the project.
2. Feature: This will contain all of the features present in the project for example products, orders, cart, etc. in an E-Commerce app. Furthermore, these feature modules can also contain sub-modules inside them as per the need and requirements of the project. Anything which is needed only at feature level will be part of their respective feature module only and not be accessed or shared to other modules. All of these feature modules must be created in a way that it can be lazy loaded.
3. Shared: Anything like components, pipes, directives, etc. which needs to be used across the project must be part of shared folder. The shared folder should not contain any services, as the singleton services are part of core and feature based services are part of their respective features.
4. Layout: Will carry the skeleton of the project like header, footer, sidebar, etc.

We can have more folders along-side:

app
|-- core
|-- features
|-- shared
|-- layout
|-- states
|-- app.component.ts|html|spec
|-- app.config.ts
|-- app.routes.ts

Here, the states folder will be related to state management - like NgRx.

Low Level Structure

Lets get into these high-level folders and understand how we can categorize it. At low level we can segregate things based on their type instead of their domain. Note, we can even further categorize into sub-features, but finally we can categorize the sub-features too based on type based. This type-based categorization provides us a way to quickly identify the elemental things, instead of keeping everything inside one folder. First let us see what are the types we are talking about:

products
|-- pages
|-- components
|-- features
|-- constants
|-- directives
|-- mocks
|-- models
|-- pipes
|-- services
|-- utils
|-- products.config.ts
|-- products.routes.ts

Talking about each folders purpose below:

• pages: Any component which is routed
• components: Any component which is not routed (child/base)
• features: Feature specific features folder. A feature can even have sub-feature inside of it that can be further lazy loaded
• constants: Feature specific constants
• directives: Feature specific directives
• guards: Feature specific guards
• mocks: Mock data for unit testing or UI screen creation
• models: Feature specific models
• pipes: Feature specific pipes
• services: Feature specific services (must set provided in parameter to specific feature, otherwise create singleton service inside core feature if service needs to be shared across)
• utils: Anything which cannot be a component, directive, service can be called and created as utils. These are classes with methods created to provide util/helper methods. For example, method to get unique id, get formatted date, get sentence case etc.

The sub-feature enables us to have more sub-feature within a feature maintaining a hierarchy. If a products feature has root level pages/components like list or detail and has further sub-features like product catalog or product history which has its own routing and pages/components, it's better to keep them one level down. This nesting helps us to quickly figure out whether they are on same level or nested.

The final folder structure will look something like this:

app
|-- core
|   |-- constants
|   |-- guards
|   |-- interceptors
|   |-- mocks
|   |-- models
|   |-- apis
|   |-- services
|   |-- core.config.ts
|-- features
|   |-- products
|   |   |-- pages
|   |   |-- components
|   |   |-- apis
|   |   |-- constants
|   |   |-- guards
|   |   |-- mocks
|   |   |-- models
|   |   |-- modules
|   |   |-- services
|   |   |-- utils
|   |   |-- products.config.ts
|   |   |-- products.routes.ts
|   |-- dashboard
|   |-- account
|   |-- orders
|   |-- carts
|-- shared
|   |-- components
|   |-- constants
|   |-- directives
|   |-- pipes
|   |-- models
|   |-- utils
|   |--shared.config.ts
|-- layout
|   |-- components
|   |	|-- header.component.ts|html|spec
|   |	|-- footer.component.ts|html|spec
|   |	|-- shell.component.ts|html|spec
|-- states
|   |-- actions
|   |-- effects
|   |-- reducers
|   |-- selectors
|   |-- app.state.ts
|-- app.component.ts|html|spec
|-- app.config.ts
|-- app.routes.ts

Keeping APIs

Keep the HTTP based API services file in Core or each Feature folders. These files can be generated from automated tool like NSwag. We can avoid using these services directly in the component instead we can plan to have a service layer for accessing the API methods.

app
|-- core
|   |-- apis
|      |-- auth.service.ts
|      |-- account.service.ts
|-- features
|   |-- products
|   |   |-- apis
|   |   |   |-- products.service.ts
|   |   |   |-- products-catalog.service.ts
|   |-- orders
|   |   |-- apis
|   |   |   |-- order.service.ts
|   |-- carts
|   |   |-- apis
|   |   |   |-- order.service.ts

Decision Making (Ask Yourself)

Sometime the decision making difficult for the team, when they may be new or fairly having lesser understanding of folder structure followed, its better to have a decision-making graph that enables developers to resolve their generic queries those comes when creating any new module, service, component, utils etc.:

• Features: For new sub-module creation:
  • Will this sub-feature contain many pages or components? (Ans: Create a sub-feature folder with config and routing, place relevant pages or components within)
  • Does lazy loading this sub-feature will help in performance? (Ans: Consider configuring lazy loading)
• Page/Component: For new component:
  • Is it routable? (Ans: Page)
  • Is it not routable? (Ans: Component)
• Service: For new service:
  • Is it shared? (Ans: Place inside core\services with provided-in parameter as root)
  • Is it not shared? (Ans: Place inside specific module with provided-in parameter as module name, e.g providedIn: ProductsModule)
• Models: For new model:
  • Is it shared? (Ans: Place inside shared\models)
  • Is it not shared? (Ans: Place inside specific module with e.g. products\models)
• Constants: For new constant:
  • Is it shared? (Ans: Place inside shared\constants)
  • Is it not shared? (Ans: Place inside specific module with e.g. products\constants)
• Utils: For helper functions:
  • Is it shared? (Ans: Place inside shared\utils)
  • Is it not shared? (Ans: Place inside specific module with e.g. products\utils)

AI Corner

Consider using below prompts in ChatGPT to get aligned with the understanding of ideal folder structuring:

• Provide ideal folder structure for Angular project considering latest version
• How can I segregate between components those are route able and those who are non-route able child only components?
• How can I manage services, shall i keep services which are consumed only in certain modules separately?
• How should I organize core, shared, layout, and feature folders in Angular latest version?
